FEATURES
· High speed access time:
100/120/150 nS (max.) · Read operating current: 15 mA (typ.)
· Erase/Programming operating current
1 mA (typ.) · Standby current: 5 mA (typ.)
· Single 5V power supply
· +14V erase/+12V programming voltage · Fully static operation
· All inputs and outputs directly TTL/CMOS
compatible · Three-state outputs
· Available packages: 28-pin 600 mil DIP and
32-pin PLCC
دریافت دیتاشیت محصول: Datasheet
